Description
The Ruijie Reyee RG-RAP2260 is a powerful enterprise-grade indoor Wi-Fi 6 ceiling access point designed for high-speed wireless performance in demanding business environments such as offices, hotels, conference rooms, schools, commercial buildings, co-working spaces, and high-density indoor deployments. Built with advanced IEEE 802.11ax (Wi-Fi 6) technology, this access point delivers combined wireless speeds of up to 2974Mbps, ensuring ultra-fast and reliable connectivity for modern bandwidth-intensive applications including HD streaming, video conferencing, cloud computing, and multi-device connectivity.
The device features dual-band 2×2 MU-MIMO architecture with 573Mbps on 2.4GHz and 2401Mbps on 5GHz, delivering highly efficient wireless performance while reducing congestion in busy network environments. The built-in high-gain omnidirectional antennas provide stable signal distribution across large indoor spaces, ensuring seamless user connectivity and better coverage consistency.
One of its standout advantages is the 2.5Gbps multi-gig uplink port, which removes wired bottlenecks and allows the AP to fully utilize its Wi-Fi 6 wireless capacity. It also includes an additional Gigabit Ethernet port for flexible wired expansion. This makes the RG-RAP2260 ideal for future-ready enterprise networks requiring higher throughput and stable wired backhaul performance.
The RG-RAP2260 supports Reyee Mesh networking, allowing easy wireless expansion without complex cabling. Combined with Ruijie Cloud centralized management, AI-powered optimization, remote monitoring, self-organizing network (SON), and standalone captive portal authentication, network deployment and maintenance become significantly easier for IT administrators and business owners.
Its compact ceiling-mounted design ensures clean installation while delivering professional-grade performance for growing enterprise wireless infrastructure.
| Specification | Details |
|---|---|
| Product Model | RG-RAP2260 |
| Product Type | Indoor Ceiling Access Point |
| Wi-Fi Standard | IEEE 802.11ax / ac / n / g / b / a |
| Wireless Technology | Wi-Fi 6 (AX3000) |
| Total Wireless Speed | 2974 Mbps |
| 2.4GHz Speed | 573 Mbps |
| 5GHz Speed | 2401 Mbps |
| MIMO Technology | Dual-Band 2×2 MU-MIMO |
| Radio Design | Dual-radio, 4 Spatial Streams |
| Antenna Type | Built-in Omnidirectional Antennas |
| 2.4GHz Antennas | 2 Built-in |
| 5GHz Antennas | 3 Built-in |
| Ethernet Ports | 1 × 2.5GbE + 1 × Gigabit RJ45 |
| Power Supply | PoE / PoE+ / DC 12V |
| Maximum Power Consumption | ≤18W |
| Maximum Concurrent Clients | Up to 512 |
| Managed Devices Capacity | Up to 300 |
| Mesh Networking | Supported |
| Cloud Management | Supported |
| Portal Authentication | Supported |
| SON Technology | Supported |
| Remote Monitoring | Supported |
| IPv6 Support | Yes |
| Mounting Options | Ceiling / Wall Mount |
| Operating Temperature | 0°C to 40°C |
| Protection Rating | IP41 |
| Dimensions | 194 × 194 × 45.1 mm |
| Weight | ≤0.65 kg |
| Color | White |
| Certification | CE / RoHS / FCC |
