Description
The Ruijie Reyee RG-NBS3200-48GT4XS-P is a high-capacity Layer 2+ cloud-managed enterprise PoE switch designed for large business networks, hotels, educational institutions, enterprise Wi-Fi deployments, CCTV surveillance systems, data-intensive office environments, and smart campus infrastructure. Built for professional networking environments, this switch delivers stable Gigabit performance, enterprise-grade management features, large-scale PoE power delivery, and ultra-fast 10G uplink connectivity, making it a highly scalable solution for modern business networking demands.
The switch is equipped with 48 Gigabit RJ45 PoE+ ports and 4 dedicated 10G SFP+ uplink ports, allowing seamless connectivity for wireless access points, IP cameras, VoIP systems, servers, NAS devices, and aggregation backbone connections. The 10G uplink architecture eliminates bandwidth bottlenecks, ensuring smooth traffic flow across large-scale enterprise deployments.
With a 370W total PoE budget, the RG-NBS3200-48GT4XS-P can directly power multiple enterprise-grade wireless APs, IP surveillance cameras, smart gateways, VoIP phones, and edge devices through Ethernet, reducing installation complexity while ensuring efficient power delivery. Each PoE port supports up to 30W output, making it fully compatible with IEEE 802.3af/at powered devices.
The switch supports advanced Layer 2+ intelligent management features, including VLAN segmentation, ACL security policies, QoS traffic prioritization, DHCP snooping, static link aggregation, IGMP snooping, port mirroring, CPU protection, ERPS redundancy, STP/RSTP, and jumbo frame support, ensuring optimized traffic control, business-grade security, and high network reliability.
Integrated with Ruijie Reyee Cloud Management, administrators can remotely deploy, monitor, configure, troubleshoot, update firmware, and visualize topology through the Reyee mobile app or cloud dashboard. This centralized management significantly reduces maintenance overhead while improving operational efficiency for distributed enterprise networks. Community feedback consistently highlights Ruijie’s strong cloud reliability for professional deployments.
Built with 6kV surge protection, dual intelligent cooling fans, industrial-grade metal construction, and 24/7 operational durability, the RG-NBS3200-48GT4XS-P ensures dependable long-term performance in mission-critical networking environments.
| Specification | Details |
|---|---|
| Product Model | RG-NBS3200-48GT4XS-P |
| Product Type | Layer 2+ Cloud Managed PoE Switch |
| RJ45 Ports | 48 × 10/100/1000 Mbps PoE+ |
| Uplink Ports | 4 × 10G SFP+ |
| PoE Standard | IEEE 802.3af / at |
| PoE Budget | 370W Total |
| Maximum PoE per Port | 30W |
| Switching Capacity | 176 Gbps |
| Packet Forwarding Rate | 130.95 Mpps |
| Packet Buffer | 16 Mbit |
| RAM | 512MB |
| Flash Memory | 256MB |
| MAC Address Table | 16K Entries |
| Maximum VLANs | 4094 |
| QoS Support | 802.1p / DSCP |
| ACL Security | Supported |
| DHCP Snooping | Supported |
| Link Aggregation | Static LAG |
| Multicast Support | IGMP Snooping v1/v2 |
| Redundancy Protocols | STP / RSTP / ERPS |
| Jumbo Frame | 9216 Bytes |
| Surge Protection | 6kV |
| Cloud Management | Reyee Cloud / Web / Mobile App |
| Cooling System | Dual Fixed Smart Fans |
| Power Supply | AC 100–240V |
| Max Power Consumption | 448W |
| Operating Temperature | 0°C to 50°C |
| Dimensions | 440 × 357.6 × 43.6 mm |
| Weight | 5.4 kg |
| Mounting Type | Standard 19-inch Rack Mount |
| Warranty | 5 Years |
